jichai JDEC JINAN diesel engine co,ltd chidong diesel engine parts H16V190ZLT2-2 GAS GENERATOR
| Place of Origin | CHINA |
|---|---|
| Brand Name | JINAN DIESEL ENGINE |
| Certification | CE |
| Model Number | H16V190ZLT-2 |
| Minimum Order Quantity | 1 |
| Price | 111 |
| Packaging Details | WOODEN CASES |
| Delivery Time | 10 |
| Supply Ability | 10 |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Product Description
Specification of B3000 Diesel Engine:
| Model | Rated power (kW) |
Rated rpm (r/min) |
Fuel consumption (g/kw.h) | Oil consumption (g/kw.h) |
Overall dimensions (mm) |
Net weight (kg) |
| BH12V190ZL | 1360 | 1500 | 202 | ≤1.0 | 2950x2280x2069 | 9300 |
| BH12V190PZL | 4189x2345x2636 | 11000 | ||||
| BH12V190ZL-3 | 1210 | 1300 | 2950x2280x2069 | 9300 | ||
| BH12V190PZL-3 | 4189x2345x2636 | 11000 | ||||
| BH12V190ZL-1 | 1160 | 1200 | 2950x2280x2069 | 9300 | ||
| BH12V190PZL-1 | 4189x2345x2636 | 11000 | ||||
| BH12V190ZL-2 | 960 | 1000 | 2950x2280x2069 | 9300 | ||
| BH12V190PZL-2 | 4189x2345x2636 | 11000 |
Technical Parameters
| Structure type | 4-stroke, direct injection combustion chamber, water-cooled, exhaust gas turbocharged, inlet air inter cooling | |
| Number and arrangement of cylinders | 12-cylinder V shape 60°angle | |
| Diameter of cylinders(mm) | 190 | |
| Stroke(mm) | 215 | |
| Total displacement(L) | 73.15 | |
| Compression ratio | 14.5:1 | |
| Exhaust temperature() | ≤650 | |
| Outlet temperature() | ≤90 | |
| Oil temperature(oil sump,) | ≤95 | |
| Steady speed change ratio (%) | ≤8(generator sets≤5) | |
| Cooling mode | Pressurized water cooling | |
| Lubrication mode | Press and spray lubrication | |
| Starting mode | Air motor or electric motor starting | |
| Jinan Guohua Green Power Equipment Co,ltd | ||
| CHIDONG/SHENGDONG 6L190,8V190,12V190,16V190 DIESEL/GAS ENGINE PARTS | ||
| Tel:+8618766952912 | ||
| Desk:86-0531-85600715 | ||
| Fax:0531-85600715 | ||
| Add:Jingshi Road 14761,Lixia District,Jinan,Shandonng,China | ||
| Email:18766952912@163.com;jichaigreenpower@163.com | ||
| Web:www.jichaigreenpower.com | ||
| WhatsApp:+8618766952912 | ||
| Skype:jinan diesel engine | ||
| Facebook:Jing Wang | ||
