jinan diesel engine

1
MOQ
1
Price
jinan diesel engine
Features Gallery Product Description Request A Quote
Features
Specifications
Basic Infomation
Place of Origin: CHINA
Brand Name: chidong
Certification: CE
Model Number: H16V190PZL
Payment & Shipping Terms
Packaging Details: WOODEN CASES
Delivery Time: 45
Supply Ability: 12
Product Description





series 6000 diesel engines
Model 12 hour power(kw)/speed(r/min) Continuous power(KW)Speed(r/min) Specific fuel consumption(g/kw.h) Specific oil consumption(g/kw.h) Overall Dimension L＊B＊H(mm) Net weigh(KG)
H12V190ZL 1740/1500 1560/1500   ≤200 ≤1.0 3234*1140*2286 9500
H12V190PZL 1740/1500 1560/1500   ≤200 ≤1.0 5417*3145*3174 13700
H12V190ZL-1 1400/1200 1260/1200   ≤200 ≤1.0 3234*1140*2286 9500
H12V190PZL-1 1400/1200 1260/1200   ≤200 ≤1.0 5417*3145*3174 13700
H12V190ZL-2 1160/1000 1040/1000   ≤200 ≤1.0 3234*1140*2286 9500
H12V190PZL-2 1160/1000 1040/1000   ≤200 ≤1.0 5417*3145*3174 13700
H16V190ZL 2400/1500 2160/1500   ≤200 ≤1.0 3525*2060*2331 13000
H16V190ZL-2 1300/1000 1170/1000   ≤200 ≤1.5 3880*2080*2540 13700
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:215mm
Total displacement:73.15L
Compression ration:14.5:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
